| ITEM | PART NUMBER | DESCRIPTION | MATERIAL | MASS | QTY |
|---|---|---|---|---|---|
|
1 |
TACS-13-2030-001-BPA |
BOTTOM PLATE ASSLY |
REF LIST |
12.024 kg |
1 |
|
2 |
MVE-13-2030-001-P-05 |
PIN |
EN8D |
1.096 kg |
2 |
|
3 |
R00B0200858 |
HEX. BOLT-M8 x 1.25 x 60L |
Stainless Steel, 440C |
0.029 kg |
2 |
|
4 |
R00B0200210 |
NYLOCK NUT-M8X1.25 |
ST52.3 |
0.006 kg |
2 |
|
5 |
ACL-NP-TH-M |
ACL NAME PLATE-M |
Aluminum 6061 |
0.012 kg |
2 |
|
6 |
R00B02001045 |
GRUB SCREW(M4X6)MM |
Steel, Mild |
0.000 kg |
1 |
Notice
The diagram provided is for reference purposes only. It may not include all details or account for specific scenarios. Please contact us for additional resources or accurate and up-to-date information.
