| Excavator Size | 1.5t - 3t |
| Attachment Width | 490mm |
| Attachment Height | 520mm |
| Teeth Thickness | 12mm |
| Grapple Opening | 700mm |
| Grapple Closing | 58mm |
| Attachment Weight | 95kg |
| Rotation | Optional |
| 360° Rotator Weight | 30 Rotator = 40kg / 50 Rotator = 55kg |
| Saw Unit Available | No |
| Pressure (bar) | 150 - 200 |
| Flow (litre) | 30 - 50 |
| Excavator Size | 3.5t - 5.5t |
| Attachment Width | 615mm |
| Attachment Height | 615mm |
| Teeth Thickness | 15mm |
| Grapple Opening | 850mm |
| Grapple Closing | 70mm |
| Attachment Weight | 165kg |
| Rotation | Optional |
| 360° Rotator Weight | 50 Rotator = 55kg / 70 Rotator = 50kg |
| Saw Unit Available | No |
| Pressure (bar) | 150 - 200 |
| Flow (litre) | 40 - 60 |
| Excavator Size | 6t - 9t |
| Attachment Width | 785mm |
| Attachment Height | 700mm |
| Teeth Thickness | 20mm |
| Grapple Opening | 1100mm |
| Grapple Closing | 98mm |
| Attachment Weight | 295kg |
| Rotation | Optional |
| 360° Rotator Weight | 70 Rotator = 50kg / 80 Rotator = 120kg |
| Saw Unit Available | No |
| Pressure (bar) | 150 - 200 |
| Flow (litre) | 40 - 60 |
| Excavator Size | 10t - 16t |
| Attachment Width | 870mm |
| Attachment Height | 795mm |
| Teeth Thickness | 25mm |
| Grapple Opening | 1750mm |
| Grapple Closing | 114mm |
| Attachment Weight | 560kg |
| Rotation | Optional |
| 360° Rotator Weight | 80 Rotator = 115kg / 120 Rotator = 135kg |
| Saw Unit Available | No |
| Pressure (bar) | 200 - 250 |
| Flow (litre) | 60 - 80 |
| Excavator Size | 16t - 25t |
| Attachment Width | 960mm |
| Attachment Height | 1035mm |
| Teeth Thickness | 30mm |
| Grapple Opening | 1860mm |
| Grapple Closing | 120mm |
| Attachment Weight | 720kg |
| Rotation | Optional |
| 360° Rotator Weight | 225kg |
| Saw Unit Available | No |
| Pressure (bar) | 200 - 250 |
| Flow (litre) | 80 - 100 |
| Excavator Size | 20t - 35t |
| Attachment Width | 1285mm |
| Attachment Height | 1105mm |
| Teeth Thickness | 40mm |
| Grapple Opening | 2200mm |
| Grapple Closing | 120mm |
| Attachment Weight | 1500kg |
| Rotation | Optional |
| 360° Rotator Weight | 170kg |
| Saw Unit Available | No |
| Pressure (bar) | 200 - 250 |
| Flow (litre) | 80 - 100 |
| Model | SX700 | SX850 | SX1100 | SX1250 | SX1400 | SX1650 |
|---|---|---|---|---|---|---|
| Excavator Size | 1.5t - 3t | 3.5t - 5.5t | 6t - 9t | 10t - 16t | 16t - 25t | 20t - 35t |
| Attachment Width | 490mm | 615mm | 785mm | 870mm | 960mm | 1285mm |
| Attachment Height | 520mm | 615mm | 700mm | 795mm | 1035mm | 1105mm |
| Teeth Thickness | 12mm | 15mm | 20mm | 25mm | 30mm | 40mm |
| Grapple Opening | 700mm | 850mm | 1100mm | 1750mm | 1860mm | 2200mm |
| Grapple Closing | 58mm | 70mm | 98mm | 114mm | 120mm | 120mm |
| Attachment Weight | 95kg | 165kg | 295kg | 560kg | 720kg | 1500kg |
| Rotation | Optional | Optional | Optional | Optional | Optional | Optional |
| 360° Rotator Weight | 30 Rotator = 40kg / 50 Rotator = 55kg | 50 Rotator = 55kg / 70 Rotator = 50kg | 70 Rotator = 50kg / 80 Rotator = 120kg | 80 Rotator = 115kg / 120 Rotator = 135kg | 225kg | 170kg |
| Saw Unit Available | No | No | No | No | No | No |
| Pressure (bar) | 150 - 200 | 150 - 200 | 150 - 200 | 200 - 250 | 200 - 250 | 200 - 250 |
| Flow (litre) | 30 - 50 | 40 - 60 | 40 - 60 | 60 - 80 | 80 - 100 | 80 - 100 |
