ITEM
|
DESCRIPTION
|
MATERIAL
|
THICKNESS
|
QTY
|
|---|---|---|---|---|
|
1
|
CUTTING EDGE
|
HB400
|
16mm
|
1
|
|
2
|
ROLL SHEET
|
ST52.3
|
8mm
|
1
|
|
3
|
TOP PLATE
|
ST52.3
|
6mm
|
1
|
|
4
|
SIDE PLATE
|
ST52.3
|
8mm
|
2
|
|
5
|
LIFTING HOOK
|
ST52.3
|
10mm
|
2
|
|
6
|
BRACKET SIDE PLATE
|
ST52.3
|
20mm
|
2
|
|
7
|
BRACKET PIN
|
EN8D
|
-
|
1
|
|
8
|
AW LOGO
|
ST52.3
|
5mm
|
2
|
|
9
|
BOTTOM WEAR STRIP
|
ST52.3
|
10mm
|
2
|
|
10
|
SERIAL NAME PLATE ASSY
|
STD
|
-
|
1
|
|
11
|
BOTTOM PLATE
|
ST52.3
|
6
|
1
|
Paint specification:
1.hex color code 3E3E3E, corresponding to RAL 9017 Traffic Black
in a Gloss Finish, for the overall bucket paint
2.For the logo, the suggested color is hex code 00AACC,
corresponding to RAL 5012 Light Blue in a Gloss Finis
|
ITEM
|
DESCRIPTION
|
MATERIAL
|
THICKNESS
|
QTY
|
|---|---|---|---|---|
|
1
|
CUTTING EDGE
|
HB400
|
16mm
|
1
|
|
2
|
ROLL SHEET
|
ST52.3
|
8mm
|
1
|
|
3
|
TOP PLATE
|
ST52.3
|
8mm
|
1
|
|
4
|
SIDE PLATE
|
ST52.3
|
8mm
|
2
|
|
5
|
LIFTING HOOK
|
ST52.3
|
10mm
|
2
|
|
6
|
BRACKET SIDE PLATE
|
ST52.3
|
20mm
|
2
|
|
7
|
BRACKET PIN
|
EN8D
|
-
|
1
|
|
8
|
AW LOGO
|
ST52.3
|
5mm
|
2
|
|
9
|
BOCE
|
HB400
|
20mm
|
1
|
|
10
|
BOTTOM WEAR STRIP
|
ST52.3
|
12mm
|
2
|
|
11
|
SERIAL NAME PLATE ASSY
|
STD
|
-
|
1
|
|
12
|
SIDE SUPPORT PLATE
|
ST52.3
|
10
|
2
|
|
13
|
GUSSET
|
ST52.3
|
8
|
2
|
|
14
|
BOTTOM PLATE
|
ST52.3
|
6
|
1
|
Paint specification:
1.hex color code 3E3E3E, corresponding to RAL 9017 Traffic Black
in a Gloss Finish, for the overall bucket paint
2.For the logo, the suggested color is hex code 00AACC,
corresponding to RAL 5012 Light Blue in a Gloss Finish
