ITEM
|
DESCRIPTION
|
MATERIAL
|
THICKNESS
|
QTY
|
|---|---|---|---|---|
|
1
|
C-CHANNEL
|
ST52.3
|
ISMC-100X50
|
2
|
|
2
|
I-BEAM
|
ST52.3
|
ISMB-100x50
|
2
|
|
3
|
BOTTOM WEAR STRIP-H
|
HB400
|
6
|
2
|
|
4
|
BOTTOM WEAR STRIP-V
|
HB400
|
6
|
2
|
|
5
|
EAR PLATE
|
ST52.3
|
16
|
2
|
|
6
|
BASE PLATE
|
ST52.3
|
16
|
1
|
|
7
|
TOP BEND PLATE
|
ST52.3
|
10
|
0
|
|
8
|
BLOCK
|
ST52.3
|
6
|
2
|
|
9
|
GUSSET-1
|
ST52.3
|
12
|
8
|
|
10
|
BOX SIDE PLATE
|
ST52.3
|
8
|
2
|
|
11
|
ACL LOGO
|
ST52.3
|
5
|
2
|
Paint specification:
Bucket:RAL 9017 Traffic Black (Gloss Finish)
logo: RAL 5012 Light Blue (Gloss Finish)
|
ITEM
|
DESCRIPTION
|
MATERIAL
|
THICKNESS
|
QTY
|
|---|---|---|---|---|
|
1
|
C-CHANNEL
|
ST52.3
|
ISMC-125X65
|
2
|
|
2
|
I-BEAM
|
ST52.3
|
ISMB-125x70
|
2
|
|
3
|
BOTTOM WEAR STRIP-H
|
HB400
|
8
|
2
|
|
4
|
BOTTOM WEAR STRIP-V
|
HB400
|
8
|
2
|
|
5
|
EAR PLATE
|
ST52.3
|
16
|
2
|
|
6
|
BASE PLATE
|
ST52.3
|
16
|
1
|
|
7
|
TOP BEND PLATE
|
ST52.3
|
12
|
1
|
|
8
|
BLOCK
|
ST52.3
|
6
|
2
|
|
9
|
GUSSET
|
ST52.3
|
10
|
8
|
|
10
|
BOX SIDE PLATE
|
ST52.3
|
10
|
2
|
|
11
|
ACL LOGO
|
ST52.3
|
5
|
2
|
Paint specification:
Bucket:RAL 9017 Traffic Black (Gloss Finish)
logo: RAL 5012 Light Blue (Gloss Finish)
|
ITEM
|
DESCRIPTION
|
MATERIAL
|
THICKNESS
|
QTY
|
|---|---|---|---|---|
|
1
|
I-BEAM
|
ST52.3
|
ISMB-175X85
|
2
|
|
2
|
C-CHANNEL
|
ST52.3
|
ISMC-175X75
|
2
|
|
3
|
BOTTOM WEAR STRIP-H
|
HB400
|
10
|
2
|
|
4
|
BOTTOM WEAR STRIP-V
|
HB400
|
10
|
2
|
|
5
|
EAR PLATE
|
ST52.3
|
16
|
2
|
|
6
|
BASE PLATE
|
ST52.3
|
16
|
1
|
|
7
|
TOP BEND PLATE
|
ST52.3
|
12
|
1
|
|
8
|
BLOCK
|
ST52.3
|
6
|
2
|
|
9
|
GUSSET
|
ST52.3
|
12
|
8
|
|
10
|
BOX SIDE PLATE
|
ST52.3
|
12
|
2
|
|
11
|
ACL LOGO
|
ST52.3
|
5
|
2
|
Paint specification:
Bucket:RAL 9017 Traffic Black (Gloss Finish)
logo: RAL 5012 Light Blue (Gloss Finish)
|
ITEM
|
DESCRIPTION
|
MATERIAL
|
THICKNESS
|
QTY
|
|---|---|---|---|---|
|
1
|
C-CHANNEL
|
ST52.3
|
ISMC-200X76
|
2
|
|
2
|
I-BEAM
|
ST52.3
|
ISMB-200x100
|
2
|
|
3
|
BOTTOM WEAR STRIP-H
|
HB400
|
10
|
2
|
|
4
|
BOTTOM WEAR STRIP-V
|
HB400
|
10
|
2
|
|
5
|
EAR PLATE
|
ST52.3
|
16
|
2
|
|
6
|
BASE PLATE
|
ST52.3
|
16
|
1
|
|
7
|
TOP BEND PLATE
|
ST52.3
|
12
|
1
|
|
8
|
BLOCK
|
ST52.3
|
6
|
2
|
|
9
|
GUSSET
|
ST52.3
|
12
|
8
|
|
10
|
BOX SIDE PLATE
|
ST52.3
|
12
|
2
|
|
11
|
ACL LOGO
|
ST52.3
|
5
|
2
|
Paint specification:
Bucket:RAL 9017 Traffic Black (Gloss Finish)
logo: RAL 5012 Light Blue (Gloss Finish)
